PTFE-MDG-2010 Ultrapure Water-Degassing

The MDG-2010 ultrapure water-degassing membrane contactor utilizes an advanced PTFE hollow fiber membrane that effectively removes dissolved oxygen while maintaining a minimum pressure drop.

Product Introduction

The MDG-2010 ultrapure water-degassing membrane contactor utilizes an advanced PTFE hollow fiber membrane that effectively removes dissolved oxygen while maintaining a minimum pressure drop. This helps prevent bubbles in the liquid from damaging the equipment. The component has a compact structure and can achieve a maximum flow rate of 2000 mL/min.

Application Field

Degassing in the beverage production industry

Degassing of laboratory water and analytical instruments

Degassing of boiler water such as oil and natural gas

Degassing of liquids in pharmaceutical production and manufacturing

Degassing of biochemical pure water

Product Features

1：

The degassing process is performed online with minimal pressure loss.

2：

Compact size, occupying minimal space.

3：

High rate of removal of dissolved oxygen.

4：

Ensures ultra-clean operation with no secondary pollution.

5：

Prolongs the life of the contactor.

Material

Components	Materia
Shell	PVC
Membrane	PTFE
Sealing ring	EPMD
Potting	Epoxy resin

Specification

Flow rate	30~120L/H
Membrane area	0.7m²
Interface	Φ12 mm tube
Maximum operating temperature	50 ℃ /122 ℉
Maximum operating pressure	0.3MPa@50℃
Weight	375g
Maximum vacuum pressure	-98KPa
Save method	Dry storage

Gas flux test of degassing membrane module

Note: For optimal performance, it is recommended that liquid be introduced slowly into the membrane contractor to prevent air from getting trapped inside.
